| AYAK BAĞLANTI EKSEN ÖLÇÜLERİ | |||
| SERİ NO | C | T | |
| MMG030060 | 94 | 77 | |
| MMG030080 | 114 | 97 | |
| MMG030100 | 134 | 117 | |
| MMG030120 | 154 | 137 | |
| MMG030140 | 174 | 157 | |
| MMG030150 | 184 | 167 | |
| MMG030160 | 194 | 177 | |
| MMG030180 | 214 | 197 | |
| MMG030200 | 234 | 217 | |
|
|
|||
| R(mm) | X(mm) | Z(mm) | D(mm) | |
| 200 | 450 | 75 | 50 |
 |
| L= KULLANILACAK MİKTAR | |||||||||
| K= HAREKET MESAFESİ | L=K/2+Y (mm) | R(mm) | X(mm) | M(mm) | Y(mm) | ||||
| Y= YUVARLANMA BOYU | 200 | 250 | 200 | 78780 | |||||
